SKU:
ALP TM93209
€ 3.755,36
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM93, featuring a 2.09:1 forward and reverse ratio, offers efficient torque for a wide range of marine applications. It delivers a max torque of 42 kgm for pleasure use and 35 kgm for commercial use, with a dry weight of 51 kg and an oil capacity of 2 liters. It operates effectively at 24 bar pressure.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM93, R=2,09:1
The Technodrive Hydraulic Marine Gearbox TM93 with a forward and reverse ratio of R=2,09:1 is an ideal solution for marine applications. It is designed for both pleasure and commercial use, providing excellent torque and efficiency.
- Article Number: TM93209
- EAN Number: 8719182621768
- Forward Ratio: R=2.09:1
- Reverse Ratio: R=2.09:1
- Max Input Power: 4500 rpm
- Dry Weight: 51kg
- Oil Quantity: 2l
- Lubricating Pressure: 0.5-1.5 bar
- Operating Pressure: 24 bar
- Max Torque (Pleasure Use): 42 kgm
- Max Torque (Commercial Use): 35 kgm
-
