SKU:
ALP TM880A260
€ 4.511,48
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM880A, with a 2.60:1 forward and reverse ratio, is built for high performance. It ensures reliable torque for both pleasure and commercial vessels, delivering a max torque of 61 kgm for pleasure and 32 kgm for commercial use. With a dry weight of 54 kg, it requires 2.5 liters of oil and operates at 24 bar pressure.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM880A, R=2.60:1
This gearbox offers a higher ratio of 2.60:1, ideal for those requiring more torque at different operational needs. It provides a balance between performance and reliability, serving both pleasure and commercial applications.
- Article number: TM880A260
- EAN number: 8719182621584
- Forward Ratio: R=2.60:1
- Reverse Ratio: R=2.60:1
- Max. input power: 4000 rpm
- Dry weight: 54kg
- Oil quantity: 2.5l
- Down angle output shaft: 10°
- Lubricating pressure: 0.5-1.5 bar
- Operating pressure: 24 bar
- Max. torque, pleasure: 61 kgm
- Max. torque, commercial: 32 kgm
-
