SKU:
ALP TM880A208
€ 4.511,48
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM880A, featuring a 2.08:1 forward and reverse ratio, is designed for inboard applications. It offers excellent torque with a max of 88 kgm for pleasure use and 57 kgm for commercial use. The gearbox is ideal for various vessels, requiring 2.5 liters of oil and performing under 24 bar pressure.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM880A, R=2.08:1
This marine gearbox is designed for inboard applications with a 2.08:1 forward and reverse ratio. It is suitable for both pleasure and commercial use, providing high torque and efficient lubrication for reliable performance.
- Article number: TM880A208
- EAN number: 8719182621584
- Forward Ratio: R=2.08:1
- Reverse Ratio: R=2.08:1
- Max. input power: 4000 rpm
- Dry weight: 54kg
- Oil quantity: 2.5l
- Down angle output shaft: 10°
- Lubricating pressure: 0.5-1.5 bar
- Operating pressure: 24 bar
- Max. torque, pleasure: 88 kgm
- Max. torque, commercial: 57 kgm
-
