SKU:
ALP TM880A153
€ 4.511,48
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM880A, with a forward and reverse ratio of 1.53:1, is perfect for larger, more demanding vessels. It provides high torque, with a max torque of 88 kgm for pleasure use and 57 kgm for commercial use. With a dry weight of 54 kg, it uses 2.5 liters of oil and operates at 24 bar pressure for reliable performance.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM880A, R=1.53:1
This powerful marine gearbox offers a 1.53:1 forward and reverse ratio, ideal for larger or more demanding vessels. It delivers high torque and is built for reliability in both commercial and pleasure applications.
- Article number: TM880A153
- EAN number: 8719182621584
- Forward Ratio: R=1.53:1
- Reverse Ratio: R=1.53:1
- Max. input power: 4000 rpm
- Dry weight: 54kg
- Oil quantity: 2.5l
- Down angle output shaft: 10°
- Lubricating pressure: 0.5-1.5 bar
- Operating pressure: 24 bar
- Max. torque, pleasure: 88 kgm
- Max. torque, commercial: 57 kgm
-
