SKU:
ALP TM485A209
€ 4.014,60
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM485A, with a 2.09:1 forward and reverse ratio, is designed for inboard applications. It provides a balanced performance suitable for both pleasure and commercial vessels, delivering a max torque of 49 kgm for pleasure use and 32 kgm for commercial use. The gearbox requires 2.6 liters of oil and operates under 24 bar pressure.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM485A, R=2.09:1
This marine gearbox is designed for inboard applications and offers a balanced performance with a forward and reverse ratio of 2.09:1. Suitable for both pleasure and commercial vessels, it delivers high torque with efficient lubrication and pressure handling.
- Article number: TM485A209
- EAN number: 8719182621225
- Forward Ratio: R=2.09:1
- Reverse Ratio: R=2.09:1
- Max. input power: 4500 rpm
- Dry weight: 36kg
- Oil quantity: 2.6l
- Down angle output shaft: 8°
- Lubricating pressure: 0.5-1.5 bar
- Operating pressure: 24 bar
- Max. torque, pleasure: 49 kgm
- Max. torque, commercial: 32 kgm
-
