The Technodrive Hydraulic Marine Gearbox TM360 with a 5.00:1 ratio is built for heavy-duty marine applications. It offers high durability, optimal performance, and a maximum torque of 118 kgm for commercial use. With a dry weight of 415 kg and an oil quantity of 11 liters, it operates at an input power of 2600 rpm with a lubricating pressure range of 0.5-1.5 bar.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM360, R=5,00:1
The Technodrive Hydraulic Marine Gearbox TM360 with a 5.00:1 ratio is built for heavier-duty marine applications, offering high durability and optimal performance in demanding conditions. This gearbox ensures efficient power transmission and smooth operation at higher loads.
- Article number: TM360500
- EAN number: 8719182620983
- Forward Ratio: R=5.00:1
- Reverse Ratio: R=5.00:1
- Max. input power: 2600 rpm
- Dry weight: 415kg
- Oil quantity: 11l
- Lubricating pressure: 0.5-1.5bar
- Operating pressure: 24bar
- Max. torque (commercial): 118kgm
-
