SKU:
ALP TM360400
€ 13.752,83
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM360 with a 4.00:1 ratio delivers optimal performance for heavy-duty commercial marine applications. It provides high torque, reliable power transmission, and a maximum torque of 118 kgm for commercial use. With a dry weight of 415 kg and an oil quantity of 11 liters, the gearbox operates with a lubricating pressure range of 0.5-1.5 bar.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM360, R=4,00:1
The Technodrive Hydraulic Marine Gearbox TM360 with a 4.00:1 ratio offers optimal performance for heavy-duty commercial marine applications. With a robust design, it delivers high torque and reliable power transmission under challenging conditions.
- Article number: TM360400
- EAN number: 8719182620983
- Forward Ratio: R=4.00:1
- Reverse Ratio: R=4.00:1
- Max. input power: 2600 rpm
- Dry weight: 415kg
- Oil quantity: 11l
- Lubricating pressure: 0.5-1.5bar
- Operating pressure: 24bar
- Max. torque (commercial): 118kgm
-
