SKU:
ALP TM360350
€ 13.752,83
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM360 with a 3.50:1 ratio is designed for reliable performance in marine applications. Offering smooth power transmission, it is suited for medium-duty commercial applications with a maximum torque of 118 kgm for commercial use. It has a dry weight of 415 kg, an oil quantity of 11 liters, and a lubricating pressure of 0.5-1.5 bar.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM360, R=3,50:1
The Technodrive Hydraulic Marine Gearbox TM360 with a 3.50:1 ratio is designed for reliable performance in various marine settings. It ensures smooth power transmission and is suited for medium-duty commercial applications with a balanced torque and power delivery.
- Article number: TM360350
- EAN number: 8719182620983
- Forward Ratio: R=3.50:1
- Reverse Ratio: R=3.50:1
- Max. input power: 2600 rpm
- Dry weight: 415kg
- Oil quantity: 11l
- Lubricating pressure: 0.5-1.5bar
- Operating pressure: 24bar
- Max. torque (commercial): 118kgm
-
