SKU:
ALP TM345A247
€ 3.103,65
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM345A with a reduction ratio of R=2.47:1 provides efficient and reliable performance with enhanced torque transmission. It has a dry weight of 25 kg, an oil quantity of 1.5 liters, and a maximum torque of 21 kgm for pleasure use. The gearbox operates with lubricating pressure between 0.5-1.5 bar and an operating pressure of 24 bar.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM345A, R=2,47:1
The Technodrive Hydraulic Marine Gearbox TM345A is engineered for efficient and reliable performance in marine applications. With a forward and reverse ratio of 2.47:1, this gearbox is ideal for smooth operation and enhanced torque transmission.
- Article number: TM345A247
- EAN number: 8719182620082
- Forward Ratio: R=2.47:1
- Reverse Ratio: R=2.47:1
- Max. input power: 4500 rpm
- Dry weight: 25kg
- Oil quantity: 1.5l
- Down angle output shaft: 8°
- Lubricating pressure: 0.5-1.5bar
- Operating pressure: 24bar
- Max. torque (pleasure): 21kgm
-
