SKU:
ALP TM345A200
€ 3.103,65
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM345A with a reduction ratio of R=2.00:1 is designed for high performance in various marine environments. It has a dry weight of 25 kg, an oil quantity of 1.5 liters, and a maximum torque of 28 kgm for pleasure use. It operates with a lubricating pressure range of 0.5-1.5 bar and an operating pressure of 24 bar.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM345A, R=2,00:1
This marine gearbox is designed for high performance with a 2.00:1 ratio, delivering smooth gear shifts and robust operation in both forward and reverse. It is ideal for various marine environments where durability is key.
- Article number: TM345A200
- EAN number: 8719182620082
- Forward Ratio: R=2.00:1
- Reverse Ratio: R=2.00:1
- Max. Input Power: 4500 rpm
- Dry Weight: 25 kg
- Oil Quantity: 1.5 l
- Down Angle Output Shaft: 8°
- Lubricating Pressure: 0.5-1.5 bar
- Operating Pressure: 24 bar
- Max. Torque (Pleasure): 28 kgm
-
