SKU:
ALP TM345A154
€ 3.103,65
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM345A with a reduction ratio of R=1.54:1 is ideal for heavy-duty marine operations. With a dry weight of 25 kg and a maximum torque of 25 kgm for pleasure use, it operates with lubricating pressure between 0.5-1.5 bar and an operating pressure of 24 bar.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM345A, R=1,54:1
Built for heavy-duty marine operations, this model features a 1.54:1 ratio for both forward and reverse. It’s well-suited for various inboard applications, offering increased torque and reliability.
- Article number: TM345A154
- EAN number: 8719182620082
- Forward Ratio: R=1.54:1
- Reverse Ratio: R=1.54:1
- Max. Input Power: 4500 rpm
- Dry Weight: 25 kg
- Oil Quantity: 1.5 l
- Down Angle Output Shaft: 8°
- Lubricating Pressure: 0.5-1.5 bar
- Operating Pressure: 24 bar
- Max. Torque (Pleasure): 25 kgm
-
