SKU:
ALP TM265A209
€ 6.695,78
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM265A with a reduction ratio of R=2.09:1 delivers advanced performance with a slightly higher torque capacity, making it ideal for both commercial and leisure marine environments. It has a dry weight of 165 kg, a lubricating pressure range of 0.5-1.5 bar, and a maximum torque of 98 kgm for pleasure use and 87 kgm for commercial use.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM265A, R=2,09:1
The Technodrive Hydraulic Marine Gearbox TM265A with a reduction ratio of R=2,09:1 offers advanced performance with a slightly higher torque capacity, ideal for both commercial and leisure marine environments.
- Article number: TM265A209
- EAN number: 8719182619604
- Inboard Forward Ratio: R=2.09:1
- Inboard Reverse Ratio: R=2.09:1
- Max. Input Power: 3000 rpm
- Dry Weight: 165kg
- Oil Quantity: 5.5 liters
- Down Angle Output Shaft: 7°
- Lubricating Pressure: 0.5-1.5 bar
- Operating Pressure: 24 bar
- Max. Torque, Pleasure: 98 kgm
- Max. Torque, Commercial: 87 kgm
-
