SKU:
ALP TM265282
€ 6.299,73
1-2 weeks delivery time
-
+
The Technodrive Hydraulic Marine Gearbox TM265 with a reduction ratio of R=2.82:1 ensures reliable power transmission and excellent performance in marine environments. With a maximum input power of 3000 rpm and a dry weight of 165 kg, it provides a maximum torque of 106 kgm for pleasure use and 83 kgm for commercial use. The lubricating pressure ranges from 0.5-1.5 bar, with an operating pressure of 24 bar.
- Description
- Ask a Question
-
Technodrive Hydraulic Marine Gearbox TM265, R=2,82:1
The Technodrive Hydraulic Marine Gearbox TM265 with a reduction ratio of R=2,82:1 is designed for marine environments, providing reliable power transmission and excellent performance.
- Article number: TM265282
- EAN number: 8719182619604
- Inboard Forward Ratio: R=2.82:1
- Inboard Reverse Ratio: R=2.82:1
- Max. Input Power: 3000 rpm
- Dry Weight: 165kg
- Oil Quantity: 5.5 liters
- Lubricating Pressure: 0.5-1.5 bar
- Operating Pressure: 24 bar
- Max. Torque, Pleasure: 106 kgm
- Max. Torque, Commercial: 83 kgm
-
