The Solé Marine Engine SM-94 with Technodrive TM93 gearbox delivers enhanced power output and torque, making it ideal for larger vessels. With 94hp and 298Nm of maximum torque, this engine provides the necessary performance for sustained use. It shares a similar design to the SM-82 with a fresh water cooling system and a reduction ratio of 2.77:1, ensuring smooth and powerful operation for heavier-duty marine applications.
- Description
- Ask a Question
-
Solé Marine Engine SM-94 With Gearbox TM93, R=2.77:1
The Solé Marine Engine SM-94, paired with the TM93 gearbox, delivers increased power output and torque, making it an ideal choice for larger vessels requiring sustained performance.
- Article Number: 9022648
- Engine Type: Turbo Diesel, 4-stroke
- No. of Cylinders: 4 in line
- Bore x Stroke: 94x120mm
- Total Displacement: 3.331cc
- Compression Ratio: 22:1
- Max Output: ISO3046/1 94hp / 69kW
- Max Speed: 2,500 rpm
- Max Torque: 298Nm at 1,700 rpm
- Combustion System: Indirect mechanical injection
- Cooling System: Fresh water with heat exchanger
- Electrical System: 12V starter motor, 2.2kW, Alternator 95A
- Weight: 362kg (Including TM345)
- Max Installation Angle: 12° (+3° discontinuous)
- Exhaust: Ø76mm
- Sea-water Intake: Ø32mm
- Fuel Intake: Ø8mm
- Fuel Return: Ø8mm
- Gearbox and Reduction: Hydraulic gearbox Technodrive TM93, R=2.77:1
-
