SKU:
ALP 9022153
€ 23.029,83
1-2 weeks delivery time
-
+
The Solé Marine Engine Mini 62 35 HP features a 4-cylinder inline 4-stroke diesel engine paired with a Technodrive TM345 hydraulic gearbox at a 2.00:1 reduction ratio, offering effective marine propulsion with robust power delivery.
- Description
- Ask a Question
-
Solé Marine Engine Mini 62 35 HP With Technodrive Gearbox TM345, R=2.00:1
This Mini 62 diesel engine offers 35 hp of power through a 4-cylinder inline 4-stroke design, paired with a Technodrive TM345 hydraulic gearbox featuring a 2.00:1 reduction ratio for effective marine propulsion.
- Article number: 9022153
- EAN number: 8719182079071
- Type: Diesel, 4-stroke
- Number of cylinders: 4 in line
- Bore x stroke: 88 x 95 mm
- Total displacement: 2,311 cc
- Compression ratio: 22:1
- Maximum output (DIN6270B): 35 hp / 26 kW
- Maximum speed: 1,700 rpm
- Maximum torque: 142 Nm at 1,700 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water cooling with heat exchanger
- Electrical system: 12V starter motor (2 kW), alternator 95 A
- Weight: 240 kg
- Maximum installation angle: 12° (+3° discontinuous)
- Exhaust diameter: Ø60 mm
- Sea-water intake diameter: Ø32 mm
- Fuel intake diameter: Ø8 mm
- Fuel return diameter: Ø6 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM345, ratio 2.00:1
-
