SKU:
ALP 9022190
€ 30.864,49
1-2 weeks delivery time
-
+
The Solé SM-103 engine, paired with the Technodrive TM93 gearbox, provides 76hp (56kW) at 2,300 rpm with a 2.09:1 reduction ratio. It features a 6-cylinder diesel design, indirect mechanical injection, and a 12V electrical system, making it a robust and dependable choice for marine inboard applications.
- Description
- Ask a Question
-
Solé Marine Diesel Engine SM-103 76HP with Technodrive Gear Box TM93, R=2.09:1
The Solé SM-103 is a robust 6-cylinder in-line marine diesel engine delivering reliable performance at sea. It includes a Technodrive TM93 hydraulic gearbox with a reduction ratio of 2.09:1, designed for inboard applications.
- Article number: 9022190
- EAN number: 8719182087472
- Engine type: Diesel, 4-stroke
- Number of cylinders: 6 in line
- Bore x stroke: 94x120mm
- Total displacement: 4.996cc
- Compression ratio: 22:1
- Maximum output: 76hp / 56kW (DIN6270B)
- Maximum speed: 2,300 rpm
- Maximum torque: 293Nm at 1,625 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water with heat exchanger
- Electrical system: 12V starter motor, 3kW alternator with 95A output
- Engine weight: 460kg
- Maximum installation angle: 12° (discontinuous +3°)
- Exhaust outlet diameter: Ø75mm
- Sea-water intake diameter: Ø30mm
- Fuel intake and return: Ø8mm
- Gearbox: Hydraulic, Technodrive TM93
- Reduction ratio: 2.09:1
-
