The Solé SM 103 engine is a powerful 6-cylinder diesel engine delivering 76hp (56kW) at 2,300 rpm. Paired with a Technodrive TM170 hydraulic gearbox, it offers a 2.94:1 reduction ratio. The engine features indirect mechanical injection, a fresh-water cooling system, and a 12V electrical system, with a weight of 460kg, making it ideal for demanding marine applications.
- Description
- Ask a Question
-
Solé Marine Diesel Engine SM 103 76 Hp With Technodrive Gear Box TM170, R=2.94:1
The SM 103 engine from Solé is a robust 6-cylinder diesel powerhouse for demanding marine uses. With a high-torque profile and the Technodrive TM170 hydraulic gearbox, it ensures smooth propulsion at a reduction ratio of 2.94:1.
- Article number: 9022198
- EAN number: 8719182087472
- Engine type: Diesel, 4-stroke
- Number of cylinders: 6 in line
- Bore x stroke: 94x120mm
- Total displacement: 4.996cc
- Compression ratio: 22:1
- Maximum output (DIN6270B): 76hp / 56kW
- Maximum speed: 2,300 rpm
- Maximum torque: 293Nm at 1,625 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water using heat exchanger
- Electrical system: 12V starter motor (3kW), Alternator 95A
- Weight: 460kg
- Maximum installation angle: 12° (+3° discontinuous)
- Exhaust diameter: Ø75mm
- Sea-water intake: Ø30mm
- Fuel intake: Ø8mm
- Fuel return: Ø8mm
- Gearbox: Technodrive TM170 (hydraulic)
- Reduction ratio: 2.94:1
-
