This SDZ 280 Turbo & Intercooler version includes a TM265A gearbox configured for a 2.30:1 reduction ratio, delivering 272 hp and 870 Nm torque. It provides optimized torque and efficiency with advanced cooling and direct injection for marine propulsion.
- Description
- Ask a Question
-
Solé Marine Diesel Engine SDZ 280 Turbo & Intercooler With Technodrive Gearbox TM265A, R=2.30:1
This variant of the SDZ 280 Turbo & Intercooler offers the same powerful 272 hp output but features a Technodrive TM265A gearbox with a reduction ratio of 2.30:1, ensuring optimized torque and marine propulsion efficiency.
- Article number: 9022287
- EAN number: 8719182091677
- Engine type: Turbo Diesel Intercooler, 4-stroke
- Cylinders: 6 in line
- Bore x stroke: 108 x 130 mm
- Total displacement: 7,150 cc
- Compression ratio: 17.5:1
- Maximum output: 272 hp / 200 kW (DIN6270B)
- Maximum speed: 2,300 rpm
- Maximum torque: 870 Nm at 1,500 rpm
- Combustion system: Direct mechanical injection
- Cooling system: Fresh water cooling using heat exchanger, cooled exhaust manifold, and turbo
- Electrical system: 2 poles, 24V starter motor (4 kW), alternator 55A
- Weight: 841 kg (including TM265)
- Maximum installation angle: 9° (+3° discontinuous)
- Exhaust diameter: Ø125 mm
- Sea-water intake diameter: Ø42 mm
- Fuel intake diameter: Ø12 mm
- Fuel return diameter: Ø12 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM265A, ratio 2.30:1
-
