The SDZ 280 Turbo & Intercooler fitted with a TM265A gearbox at 2.09:1 reduction ratio offers 272 hp and 870 Nm torque, featuring direct mechanical injection, fresh water cooling, and a six-cylinder turbo diesel engine for high-demand marine environments.
- Description
- Ask a Question
-
Solé Marine Diesel Engine SDZ 280 Turbo & Intercooler With Technodrive Gearbox TM265A, R=2.09:1
This SDZ 280 Turbo & Intercooler engine delivers 272 hp and is equipped with a Technodrive TM265A hydraulic gearbox featuring a 2.09:1 reduction ratio. It offers powerful torque and advanced cooling for demanding marine applications.
- Article number: 9022286
- EAN number: 8719182091677
- Engine type: Turbo Diesel Intercooler, 4-stroke
- Cylinders: 6 in line
- Bore x stroke: 108 x 130 mm
- Total displacement: 7,150 cc
- Compression ratio: 17.5:1
- Maximum output: 272 hp / 200 kW (DIN6270B)
- Maximum speed: 2,300 rpm
- Maximum torque: 870 Nm at 1,500 rpm
- Combustion system: Direct mechanical injection
- Cooling system: Fresh water cooling using heat exchanger, cooled exhaust manifold, and turbo
- Electrical system: 2 poles, 24V starter motor (4 kW), alternator 55A
- Weight: 841 kg (including TM265)
- Maximum installation angle: 9° (+3° discontinuous)
- Exhaust diameter: Ø125 mm
- Sea-water intake diameter: Ø42 mm
- Fuel intake diameter: Ø12 mm
- Fuel return diameter: Ø12 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM265A, ratio 2.09:1
-
