SKU:
ALP 9022275
€ 50.876,51
1-2 weeks delivery time
-
+
With a TM265A gearbox set at a 2.30:1 reduction ratio, this SDZ 205 Turbo model provides consistent marine performance, offering 197 hp and 667 Nm torque, supported by fresh water cooling, direct mechanical injection, and a 6-cylinder turbocharged engine.
- Description
- Ask a Question
-
Solé Marine Diesel Engine SDZ 205 Turbo With Technodrive Gearbox TM265A, R=2.30:1
This diesel engine variant comes with the TM265A Technodrive gearbox configured with a reduction ratio of 2.30:1, offering efficient power delivery and consistent marine performance.
- Article number: 9022275
- EAN number: 8719182091073
- Engine type: Turbo Diesel Intercooler, 4-stroke
- Cylinders: 6 in line
- Bore x stroke: 108 x 130 mm
- Total displacement: 7,146 cc
- Compression ratio: 17.6:1
- Maximum output: 197 hp / 145 kW (DIN6270B)
- Maximum speed: 2,300 rpm
- Maximum torque: 667 Nm at 1,500 rpm
- Combustion system: Direct mechanical injection
- Cooling system: Fresh water cooling using heat exchanger, cooled exhaust manifold, and turbo
- Electrical system: 2 poles, 24V starter motor (4 kW), alternator 55A
- Weight: 788 kg (including TM170)
- Maximum installation angle: 9° (+3° discontinuous)
- Exhaust diameter: Ø125 mm
- Sea-water intake diameter: Ø42 mm
- Fuel intake diameter: Ø12 mm
- Fuel return diameter: Ø12 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM265A, ratio 2.30:1
-
