SKU:
ALP 9022274
€ 50.876,51
1-2 weeks delivery time
-
+
The SDZ 205 Turbo equipped with the TM265A hydraulic gearbox at a 2.09:1 reduction ratio maintains the same power and efficiency, featuring a six-cylinder turbo diesel intercooler engine with advanced cooling and direct injection for dependable marine use.
- Description
- Ask a Question
-
Solé Marine Diesel Engine SDZ 205 Turbo With Technodrive Gearbox TM265A, R=2.09:1
This version of the SDZ 205 Turbo diesel engine is equipped with a hydraulic Technodrive gearbox TM265A, optimized for a reduction ratio of 2.09:1, delivering the same reliable power and efficiency as the other models.
- Article number: 9022274
- EAN number: 8719182091073
- Engine type: Turbo Diesel Intercooler, 4-stroke
- Cylinders: 6 in line
- Bore x stroke: 108 x 130 mm
- Total displacement: 7,146 cc
- Compression ratio: 17.6:1
- Maximum output: 197 hp / 145 kW (DIN6270B)
- Maximum speed: 2,300 rpm
- Maximum torque: 667 Nm at 1,500 rpm
- Combustion system: Direct mechanical injection
- Cooling system: Fresh water cooling using heat exchanger, cooled exhaust manifold, and turbo
- Electrical system: 2 poles, 24V starter motor (4 kW), alternator 55A
- Weight: 788 kg (including TM170)
- Maximum installation angle: 9° (+3° discontinuous)
- Exhaust diameter: Ø125 mm
- Sea-water intake diameter: Ø42 mm
- Fuel intake diameter: Ø12 mm
- Fuel return diameter: Ø12 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM265A, ratio 2.09:1
-
