SKU:
ALP 9022273
€ 50.745,94
1-2 weeks delivery time
-
+
This SDZ 205 Turbo version with a TM265 gearbox and a higher reduction ratio of 2.82:1 offers robust marine performance and advanced cooling features, producing 197 hp and 667 Nm torque. The engine includes direct mechanical injection and fresh water cooling with heat exchanger and cooled turbo components.
- Description
- Ask a Question
-
Solé Marine Diesel Engine SDZ 205 Turbo With Technodrive Gearbox TM265, R=2.82:1
This marine diesel engine combines robust performance and advanced cooling for reliable operation. It is designed with a 6-cylinder turbo diesel intercooler engine and paired with a Technodrive hydraulic gearbox featuring a reduction ratio of 2.82:1.
- Article number: 9022273
- EAN number: 8719182091073
- Engine type: Turbo Diesel Intercooler, 4-stroke
- Cylinders: 6 in line
- Bore x stroke: 108 x 130 mm
- Total displacement: 7,146 cc
- Compression ratio: 17.6:1
- Maximum output: 197 hp / 145 kW (DIN6270B)
- Maximum speed: 2,300 rpm
- Maximum torque: 667 Nm at 1,500 rpm
- Combustion system: Direct mechanical injection
- Cooling system: Fresh water cooling using heat exchanger, cooled exhaust manifold, and turbo
- Electrical system: 2 poles, 24V starter motor (4 kW), alternator 55A
- Weight: 788 kg (including TM170)
- Maximum installation angle: 9° (+3° discontinuous)
- Exhaust diameter: Ø125 mm
- Sea-water intake diameter: Ø42 mm
- Fuel intake diameter: Ø12 mm
- Fuel return diameter: Ø12 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM265, ratio 2.82:1
-
