SKU:
ALP 9022270
€ 46.975,93
1-2 weeks delivery time
-
+
The Solé Marine Diesel Engine SDZ 205 Turbo with Technodrive Gearbox TM170 features a six-cylinder turbocharged and intercooled design, offering 197 hp and 667 Nm torque, with advanced cooling and direct mechanical injection for reliable marine performance. It includes a hydraulic TM170 gearbox with a reduction ratio of 2.04:1.
- Description
- Ask a Question
-
Solé Marine Diesel Engine SDZ 205 Turbo With Technodrive Gearbox TM170, R=2.04:1
This six-cylinder turbocharged and intercooled marine diesel engine offers enhanced power and torque for demanding applications. It incorporates advanced cooling and injection systems to ensure reliable and efficient operation.
- Article number: 9022270
- EAN number: 8719182091073
- Type: Turbo Diesel Intercooler, 4-stroke
- Cylinders: 6 in line
- Bore x stroke: 108 x 130 mm
- Total displacement: 7,146 cc
- Compression ratio: 17.6:1
- Max output (DIN6270B): 197 hp / 145 kW
- Max speed: 2,300 rpm
- Max torque: 667 Nm at 1,500 rpm
- Combustion system: Direct mechanical injection
- Cooling system: Fresh water cooling with heat exchanger, cooled exhaust manifold and turbo
- Electrical system: 2 poles, 24V starter motor 4 kW, alternator 55A
- Weight: 788 kg (including TM170 gearbox)
- Maximum installation angle: 9° (+3° discontinuous)
- Exhaust diameter: Ø125 mm
- Sea-water intake diameter: Ø42 mm
- Fuel intake diameter: Ø12 mm
- Fuel return diameter: Ø12 mm
- Gearbox and reduction: Hydraulic Technodrive TM170, ratio 2.04:1
-
