SKU:
ALP 9022170
€ 25.264,99
1-2 weeks delivery time
-
+
The Solé Marine Diesel Engine Mini 74 with Technodrive TM345 gearbox (R=2.00:1) is designed for smaller marine vessels, offering a 70 hp / 51.4 kW output. It features a 4-cylinder, 3.331 cc engine with indirect mechanical injection and a fresh water cooling system. The unit weighs 340 kg, with a max speed of 2500 rpm, and comes with a hydraulic gearbox providing a 2.00:1 reduction ratio.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 74 With Technodrive Gearbox TM345, R=2.00:1
The Solé Marine Diesel Engine Mini 74 with Technodrive TM345 gearbox offers a compact yet powerful engine solution for inboard marine applications. Its 70hp output and hydraulic gearbox make it ideal for a variety of smaller vessels. Below are its specifications:
- Article number: 9022170
- EAN number: 8719182085850
- Type: Diesel, 4-stroke
- Number of cylinders: 4 in line
- Bore x Stroke: 94 x 120 mm
- Total displacement: 3.331 cc
- Compression ratio: 22:1
- Max. output: 70 hp / 51.4 kW (DIN6270B)
- Max. speed: 2500 rpm
- Max. torque: 200 Nm at 1500 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water with heat exchanger
- Electrical system: 12V starter motor, 2.2 kW, 95A alternator
- Weight: 340 kg
- Max. installation angle: 12° (+3° discontinuous)
- Exhaust: Ø76 mm
- Sea-water intake: Ø32 mm
- Fuel intake: Ø8 mm
- Fuel return: Ø8 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM345, R=2.00:1
-
