SKU:
ALP 9022178
€ 5.637,02
1-2 weeks delivery time
-
+
The Solé Marine Diesel Engine Mini 74 with Technodrive TM93 gearbox (R=2.77:1) offers maximum performance with a reduction ratio of 2.77:1. The 4-cylinder engine provides 70 hp / 51.4 kW output and operates at 2500 rpm, with a hydraulic gearbox and fresh water cooling system. It weighs 340 kg and is suited for a variety of marine applications.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 74 With Hydraulic Technodrive Gearbox TM93, R=2.77:1
This variant of the Solé Marine Diesel Engine Mini 74 is equipped with a hydraulic Technodrive TM93 gearbox offering a reduction ratio of 2.77:1. Like the other versions, it is designed for maximum performance and durability in the marine environment. The detailed specifications are listed below:
- Article Number: 9022178
- EAN Number: 8719182085850
- Engine Type: Diesel, 4-stroke
- Number of Cylinders: 4 in line
- Bore x Stroke: 94x120mm
- Total Displacement: 3.331cc
- Compression Ratio: 22:1
- Max Output: 70hp / 51.4kW (DIN6270B)
- Max Speed: 2,500 rpm
- Max Torque: 200Nm at 1,500 rpm
- Combustion System: Indirect mechanical injection
- Cooling System: Fresh water with heat exchanger
- Electrical System: 12V starter motor (2.2kW), Alternator (95A)
- Weight: 340kg
- Max Installation Angle: 12° (+3° discontinuous)
- Exhaust: Ø76mm
- Sea-water Intake: Ø32mm
- Fuel Intake: Ø8mm
- Fuel Return: Ø8mm
- Gearbox and Reduction: Hydraulic Technodrive TM93, R=2.77:1
-
