The Solé Marine Diesel Engine Mini 74 with Technodrive TM93 gearbox (R=2.09:1) is a compact yet powerful solution for marine applications. The 4-cylinder engine produces 70 hp / 51.4 kW, operates at 2500 rpm, and has a hydraulic Technodrive gearbox with a 2.09:1 reduction ratio. It features a fresh water cooling system and weighs 340 kg.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 74 With Hydraulic Technodrive Gearbox TM93, R=2.09:1
This Solé Marine Diesel Engine Mini 74 is designed for inboard use, offering robust performance for a variety of marine applications. It is paired with a hydraulic Technodrive TM93 gearbox featuring a reduction ratio of 2.09:1. Explore its key features below:
- Article Number: 9022370
- EAN Number: 8719182085850
- Engine Type: Diesel, 4-stroke
- Number of Cylinders: 4 in line
- Bore x Stroke: 94x120mm
- Total Displacement: 3.331cc
- Compression Ratio: 22:1
- Max Output: 70hp / 51.4kW (DIN6270B)
- Max Speed: 2,500 rpm
- Max Torque: 200Nm at 1,500 rpm
- Combustion System: Indirect mechanical injection
- Cooling System: Fresh water with heat exchanger
- Electrical System: 12V starter motor (2.2kW), Alternator (95A)
- Weight: 340kg
- Max Installation Angle: 12° (+3° discontinuous)
- Exhaust: Ø76mm
- Sea-water Intake: Ø32mm
- Fuel Intake: Ø8mm
- Fuel Return: Ø8mm
- Gearbox and Reduction: Hydraulic Technodrive TM93, R=2.09:1
-
