SKU:
ALP 9022050
€ 16.515,49
1-2 weeks delivery time
-
+
This Mini 62 diesel engine model combines a 35 HP output with a Technodrive TMC260 gearbox at a 2.00:1 reduction ratio, designed for efficient and smooth inboard marine operation.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 62 35 HP With Technodrive Gear Box TMC260, R=2.00:1
This reliable marine diesel engine offers a robust 35 HP output combined with a Technodrive TMC260 gearbox featuring a reduction ratio of 2.00:1, designed for efficient and smooth inboard operation.
- Article number: 9022050
- EAN number: 8719182079071
- Engine type: Diesel, 4-stroke
- Cylinders: 4 in line
- Bore x stroke: 88x95mm
- Total displacement: 2.311cc
- Compression ratio: 22:1
- Maximum output: DIN6270B 35hp / 26kW
- Maximum speed: 1,700 rpm
- Maximum torque: 142Nm at 1,700 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water cooled using a heat exchanger
- Electrical system: 12V starter motor, 2kW; Alternator 95A
- Weight: 240kg
- Maximum installation angle: 12° (+3° discontinuous)
- Exhaust diameter: Ø60mm
- Sea-water intake diameter: Ø32mm
- Fuel intake diameter: Ø8mm
- Fuel return diameter: Ø6mm
- Gearbox and reduction: Technodrive TMC260 gearbox with R=2.00:1
-
