The Solé Marine Diesel Engine Mini 55 Turbo with Technodrive Gearbox TMC260 and a reduction ratio of 2.00:1 is a reliable inboard turbo diesel engine that offers efficient performance combined with smooth power delivery through its gearbox.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 55 Turbo With Technodrive Gear Box TMC260, R=2.00:1
This reliable inboard turbo diesel engine combines efficient performance with a Technodrive TMC260 gearbox, offering a reduction ratio of 2.00:1 for smooth power delivery.
- Article number: 9022200
- EAN number: 8719182088318
- Type: Turbo Diesel, 4-stroke
- Number of cylinders: 4 in line
- Bore x stroke: 78 x 92 mm
- Total displacement: 1,758 cc
- Compression ratio: 22:1
- Maximum output (DIN6270B): 52 hp / 38.3 kW
- Maximum speed: 3,000 rpm
- Maximum torque: 125 Nm at 1,900 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water cooling with heat exchanger
- Electrical system: 12V starter motor (1.7 kW), alternator 95 A
- Weight: 189 kg
- Maximum installation angle: 12° (+3° discontinuous)
- Exhaust diameter: Ø60 mm
- Sea-water intake diameter: Ø26 mm
- Fuel intake diameter: Ø6 mm
- Fuel return diameter: Ø5 mm
- Gearbox and reduction: Gearbox Technodrive TMC260, ratio 2.00:1
-
