SKU:
ALP 9022207
€ 17.300,68
1-2 weeks delivery time
-
+
This Solé Mini 55 Turbo model combines a turbocharged 4-cylinder diesel engine with a Technodrive hydraulic TM345 gearbox offering a 2.47:1 reduction ratio, delivering 52 hp and optimized for inboard marine use, weighing 189 kg.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 55 Turbo With Technodrive Gear Box TM345, R=2.47:1
This compact and powerful marine diesel engine is designed for inboard applications, featuring a turbocharged 4-stroke diesel setup and a Technodrive hydraulic gearbox with a 2.47:1 reduction ratio.
- Article number: 9022207
- EAN number: 8719182088318
- Type: Turbo Diesel, 4-stroke
- Number of cylinders: 4 in line
- Bore x stroke: 78 x 92 mm
- Total displacement: 1,758 cc
- Compression ratio: 22:1
- Maximum output (DIN6270B): 52 hp / 38.3 kW
- Maximum speed: 3,000 rpm
- Maximum torque: 125 Nm at 1,900 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water cooling with heat exchanger
- Electrical system: 12V starter motor (1.7 kW), alternator 95 A
- Weight: 189 kg
- Maximum installation angle: 12° (+3° discontinuous)
- Exhaust diameter: Ø60 mm
- Sea-water intake diameter: Ø26 mm
- Fuel intake diameter: Ø6 mm
- Fuel return diameter: Ø5 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM345, ratio 2.47:1
-
