The Solé Mini 55 Turbo is a turbocharged 4-cylinder diesel engine paired with a hydraulic Technodrive TM345 gearbox at a 2.00:1 reduction ratio, delivering 52 hp and enhanced torque for marine vessels, with fresh water cooling and a weight of 189 kg.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 55 Turbo With Technodrive Gear Box TM345, R=2.00:1
This turbocharged diesel engine delivers enhanced power and torque for marine vessels, paired with a hydraulic gearbox to ensure smooth operation and efficiency in demanding conditions.
- Article number: 9022206
- EAN number: 8719182088318
- Engine type: Turbo Diesel, 4-stroke
- Cylinders: 4 in line
- Bore x stroke: 78 x 92 mm
- Total displacement: 1,758 cc
- Compression ratio: 22:1
- Maximum output: 52 hp (38.3 kW) according to DIN6270B
- Maximum speed: 3,000 rpm
- Maximum torque: 125 Nm at 1,900 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water with heat exchanger
- Electrical system: 12V starter motor (1.7 kW), Alternator 95A
- Weight: 189 kg
- Maximum installation angle: 12° (+3° discontinuous)
- Exhaust diameter: Ø60 mm
- Sea-water intake diameter: Ø26 mm
- Fuel intake diameter: Ø6 mm
- Fuel return diameter: Ø5 mm
- Gearbox and reduction: Hydraulic gearbox Technodrive TM345, ratio 2.00:1
-
