SKU:
ALP 9022041
€ 12.603,31
1-2 weeks delivery time
-
+
The Solé Marine Diesel Engine Mini 44 with Technodrive Gear Box TMC60P and a reduction ratio of 1.55:1 is a robust 4-cylinder, 4-stroke diesel engine designed for reliable performance, featuring a 42 hp output and fresh water cooling system.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 44 With Technodrive Gear Box TMC60P, R=1.55:1
This inboard marine diesel engine Mini 44 features a Technodrive TMC60P gearbox with a reduction ratio of 1.55:1. It is a robust 4-cylinder, 4-stroke engine designed for reliable performance and efficiency in marine applications.
- Article Number: 9022041
- EAN Number: 8719182078531
- Type: Diesel, 4-stroke
- Cylinders: 4 in line
- Bore x Stroke: 78 x 92 mm
- Total Displacement: 1,758 cc
- Compression Ratio: 22:1
- Max Output: 42 hp / 30.9 kW (DIN6270B)
- Max Speed: 3,000 rpm
- Max Torque: 106 Nm at 1,800 rpm
- Combustion System: Indirect mechanical injection
- Cooling System: Fresh water with heat exchanger
- Electrical System: 12V starter motor (2 kW), Alternator 95A
- Weight: 190 kg
- Max Installation Angle: 12° (+3° discontinuous)
- Exhaust Diameter: Ø50 mm
- Sea-water Intake Diameter: Ø20 mm
- Fuel Intake Diameter: Ø6 mm
- Fuel Return Diameter: Ø5 mm
- Gearbox: Technodrive TMC60P, Reduction Ratio 1.55:1
- Lake Constance Approval: Yes
-
