SKU:
ALP 9022010
€ 8.250,77
1-2 weeks delivery time
-
+
The Solé Marine Diesel Engine Mini 17 with Technodrive Gear Box TMC40L (R=2.00:1) offers a robust two-cylinder 4-stroke diesel engine with 16hp output, ideal for various inboard marine setups with fresh water cooling and a 12V electrical system.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 17 With Technodrive Gear Box TMC40L, R=2.00:1
This version of the Solé Marine Mini 17, based on Mitsubishi, includes the Technodrive TMC40L gearbox with a 2.00:1 reduction ratio. It's built for performance with a robust two-cylinder 4-stroke diesel engine, making it suitable for various inboard marine setups.
- Article number: 9022010
- EAN number: 8719182075530
- Engine type: Diesel, 4-stroke
- No. of cylinders: 2 in line
- Bore x stroke: 76x70mm
- Total displacement: 635cc
- Compression ratio: 23:1
- Max. output: DIN6270B 16hp / 11.77kW
- Max. speed: 3,600 rpm
- Max. torque: 32Nm at 2,300 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water using heat exchanger
- Electrical system: 12V starter motor, 1.2kW, Alternator 75A
- Weight: 98kg
- Weight with Saildrive: 127kg (incl. polyester base)
- Max. installation angle: 22° (+3° discontinuous)
- Exhaust: Ø40mm
- Sea-water intake: Ø20mm
- Fuel intake: Ø6mm
- Fuel return: Ø5mm
- Gearbox and reduction: Technodrive TMC40, R=2.00:1
- Lake Constance Approval: Yes
-
