SKU:
ALP 9022162
€ 14.697,55
1-2 weeks delivery time
-
+
The Solé Marine Diesel Engine Mini 17/SD integrates a saildrive system with Seaprop technology for quiet, smooth propulsion, combining a strong Mini 17 core engine with enhanced maneuverability.
- Description
- Ask a Question
-
Solé Marine Diesel Engine Mini 17/SD With Technodrive Seaprop Saildrive, R=2.15:1
Marine diesel engine integrated with a saildrive system, ideal for quiet and smooth propulsion. Offers the same robust core as the Mini 17, now paired with Seaprop technology for optimized maneuverability.
- Article number: 9022162
- EAN number: 8719182075530
- Engine type: Diesel, 4-stroke
- Number of cylinders: 2 in line
- Bore x stroke: 76x70mm
- Total displacement: 635cc
- Compression ratio: 23:1
- Maximum output (DIN6270B): 16hp / 11,77kW
- Maximum speed: 3.600 rpm
- Maximum torque: 32Nm at 2.300 rpm
- Combustion system: Indirect mechanical injection
- Cooling system: Fresh water using heat exchanger
- Electrical system: 12V starter motor (1.2kW), Alternator 75A
- Engine weight: 98kg
- Weight with Saildrive: 127kg (including polyester base)
- Maximum installation angle: 22° (+3° discontinuous)
- Exhaust diameter: Ø40mm
- Sea-water intake: Ø20mm
- Fuel intake: Ø6mm
- Fuel return: Ø5mm
- Gearbox: Technodrive Sea Prop - Saildrive with base, Reduction R=2.15:1
- Lake Constance approval: Yes
-
