SKU:
ALP HC5357
€ 1.743,03
1-2 weeks delivery time
-
+
The SeaStar HC5357 Capilano hydraulic cylinder is a heavy-duty brass marine cylinder with single-axis articulation, designed for easy installation and reliable performance without air leaks or pressure drops in hydraulic steering systems.
- Description
- Ask a Question
-
SeaStar HC5357 - Capilano Cylinder 181kgm For Hydraulic Inboard Steering System (BA200-7TMC)
This Capilano marine hydraulic cylinder is engineered from heavy duty brass for strength and reliability. Featuring single-axis articulation, it is straightforward to install on both single and dual rudder boats. The cylinder is built to maintain hydraulic integrity without air leaks or pressure drops, providing dependable steering for inboard vessels.
- 2 Hydraulic Lines
- Heavy-Duty Construction
- Stainless and Bronze Mounting Hardware
- Heavy Duty Brass Cylinder
- Bleed fittings included
- Chrome plated stainless steel rod
- Not an air-pressurized system – no air leaks or pressure drops
- Stroke: 7" (178 mm)
- Bore Diameter: 2.00"
- Balanced Hydraulic Cylinder
- Displacement: 18.9 cubic inches
- Torque at 1000 psi @ 35°: 13,200 in/lbs
- Control Type: BA200-7TMC
- Series: Capilano
- Body Material: Bronze
- Fittings Size: 1/2"
- Volume: 377 cc
- Rudder Torque: 181 kgm
- Article Number: HC5357
-
