SKU:
TN 00360973
€ 762,54
1-2 weeks delivery time
-
+
The Fusion SG-24DA61500 is a 6-channel, 24-volt marine amplifier built to withstand harsh environments, delivering up to 1500 watts peak power with efficient Class-D design, multiple speaker configurations, and advanced sound filters for superior audio performance.
- Description
- Ask a Question
-
Fusion SG-24DA61500 - 6-Channel 24 Volt Amplifier
Designed specifically for 24 Volt on-board systems, this amplifier meets Fusion's True-Marine standards. It has undergone rigorous testing to ensure durability against salt mist, temperature fluctuations, vibration, and UV exposure. Featuring a highly efficient Class-D design, it delivers more power with lower energy consumption compared to traditional Class-AB amplifiers, enhancing the audio experience with greater output to connected speakers and subwoofers.
- Supports configurations of 6 speakers at 4 Ohm or 12 speakers at 2 Ohm
- Supports setups with 4 speakers at 4 Ohm plus 1 subwoofer
- Supports setups with 8 speakers at 2 Ohm plus 1 subwoofer or 2 subwoofers
- Includes built-in variable bass boost, subsonic filter, and adjustable low/high crossover filters for improved sound quality and system protection
- Requires adequate ventilation to ensure optimal performance
- Order number: 00360973
- Supplier code: 010-02556-00
- Barcode: 753759268497
- Model: SG-24DA61500
- Peak Power: 1500 Watt
- Voltage range: 21.6 to 32 Volts
- Dimensions (HxWxD): 210 x 420 x 57 mm
- Frequency response: 20Hz - 20kHz
- RMS power output at 4 Ohms: 6 x 100 Watt
- RMS power output at 2 Ohms: 6 x 140 Watt
- Fuses: 3 x 20 A
- Maximum power consumption: 75 A
- Operating temperature range: 0 to 50 °C
-
