Baratta SSCV-A Marine Bain Marie Counter With Hot Cabinet

Article BARATTA-SSCV-A

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Baratta SSCV-A Marine Bain Marie Counter With Hot Cabinet is a high-performance kitchen solution designed for marine environments, available in several sizes to meet various needs. It features a robust AISI 304 stainless steel construction, ensuring durability and resistance to corrosion. The counter includes multiple well configurations for GN containers, with models accommodating from 2 to 5 GN 1/1 wells. Each model offers different dimensions, from 800 mm to 2000 mm in length, and varying numbers of doors (1 to 3). The Bain Marie operates with multiple rated voltages (115/3/60, 230/3/50-60, 400/3/50, 415/3/50-60, 440/3/60) and has a total power range from 3.3 kW to 6.1 kW, making it a versatile and efficient choice for marine catering needs.

Description
Ask a Question

Baratta SSCV-A Marine Bain Marie Counter With Hot Cabinet

The Baratta SSCV-A Marine Bain Marie Counter With Hot Cabinet is designed for durability and efficiency in a marine environment. Available in various models to suit different needs, it combines functionality with high-quality materials.

Models and Dimensions
- SSCV-8A:
  - Length: 800 mm
  - Width: 800 mm
  - Height: 900 mm
  - Well Dimensions: 2x GN 1/1
  - Number of Doors: 1
  - Rated Voltage: 115/3/60, 230/3/50-60, 400/3/50, 415/3/50-60, 440/3/60
  - Total Power: 3.3 kW
- SSCV-12A:
  - Length: 1200 mm
  - Width: 800 mm
  - Height: 900 mm
  - Well Dimensions: 3x GN 1/1
  - Number of Doors: 2
  - Rated Voltage: 115/3/60, 230/3/50-60, 400/3/50, 415/3/50-60, 440/3/60
  - Total Power: 3.3 kW
- SSCV-15A:
  - Length: 1500 mm
  - Width: 800 mm
  - Height: 900 mm
  - Well Dimensions: 4x GN 1/1
  - Number of Doors: 2
  - Rated Voltage: 115/3/60, 230/3/50-60, 400/3/50, 415/3/50-60, 440/3/60
  - Total Power: 5.6 kW
- SSCV-20A:
  - Length: 2000 mm
  - Width: 800 mm
  - Height: 900 mm
  - Well Dimensions: 5x GN 1/1
  - Number of Doors: 3
  - Rated Voltage: 115/3/60, 230/3/50-60, 400/3/50, 415/3/50-60, 440/3/60
  - Total Power: 6.1 kW
Materials and Construction

The Bain Marie counter is constructed from high-grade AISI 304 stainless steel, ensuring longevity and resistance to corrosion. It features multiple well configurations to accommodate various sizes of GN containers.

Technical Specifications
- Material: AISI 304 Stainless Steel
- Well Dimensions: Varies by model (2x GN 1/1 to 5x GN 1/1)
- Number of Doors: 1 to 3 depending on model
- Rated Voltage: 115/3/60, 230/3/50-60, 400/3/50, 415/3/50-60, 440/3/60
- Total Power: Ranges from 3.3 kW to 6.1 kW
