The Victron SmartSolar MPPT RS 450/100-MC4 is a high-efficiency 48V solar charge controller designed for large PV arrays. It features dual independent MPPT inputs, up to 450V PV voltage, and a 100A battery charging current. This isolated controller integrates Bluetooth, a full-color display, VE.Can for multi-unit syncing, PV insulation monitoring, and MC4 connectors per input. Ideal for off-grid, backup, and commercial solar systems demanding precise multi-source tracking and safety.
- Description
- Ask a Question
-
Victron Energy SmartSolar MPPT RS 450/100-MC4 Charge Controller, 48V, 100A
The SmartSolar MPPT RS 450/100-MC4 is a 48V isolated solar charge controller with two independent MPPT inputs, optimized for high-voltage PV arrays up to 450V. It delivers up to 100A of battery charging current and supports multi-stage programmable charging. With built-in Bluetooth, PV isolation monitoring, VE.Can syncing (up to 25 units), and a full display interface, this controller is perfect for demanding residential, commercial, and off-grid PV systems.
Parameter Specification Model SmartSolar MPPT RS 450/100-MC4 Battery Voltage 48 V (programmable 36–60 V) Max Charge Current 100 A Max Charge Power 5.8 kW @ 57.6 V PV Input Voltage Range 65–450 VDC (120 VDC startup) MPPT Trackers 2 independent inputs Max PV Input Current 16 A per tracker (20 A short-circuit limit) Max PV Array Size 2x 7200 Wp (360 V x 20 A) PV Isolation Monitoring Yes (100 kΩ threshold) Max Efficiency 96 % Data Interfaces VE.Can, VE.Direct, Bluetooth Display Yes (with parameter readout) Programmable Relay Yes (4A up to 35VDC, 1A up to 70VDC) Protection Reverse PV, output short, over-temp Operating Temp -40°C to +60°C (fan-assisted) Enclosure Steel, blue RAL 5012, IP21 PV Connection 2x MC4 pairs (1 pair per tracker) Battery Connection 2x M8 bolts (1 pos, 1 neg) Weight 7.9 kg Dimensions (HxWxD) 440 x 313 x 126 mm
Key Features:
- Ultra-fast MPPT with dual tracker inputs
- 450 VDC PV input, ideal for long PV strings
- Bluetooth connectivity via VictronConnect
- Galvanically isolated PV and battery sections
- PV insulation resistance monitoring
- VE.Can communication for parallel operation
- Low self-consumption and high efficiency
Applications:
- Off-grid solar and hybrid systems
- Commercial and industrial rooftops
- Remote telecom and agricultural installations
- Battery charging from high-voltage solar arrays
Looking for a different Victron Smart Solar Charge Controllers? Explore our full Victron SmartSolar RS product range.
Documents
Victron Energy SmartSolar MPPT RS Size: 391,4 Kb -
