SKU:
CN VISCC010010000
€ 24,68
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The Victron BlueSolar PWM-Light 12/24V-10A is a compact, automatic voltage-sensing PWM charge controller with 10A current capacity. Ideal for small off-grid solar systems, it includes three-stage charging, integrated low-voltage load disconnect, and a built-in lighting timer programmable via two-digit LED. Designed for efficient control of solar-powered DC lighting and appliances with electronic protections and minimal power draw.
- Description
- Ask a Question
-
Victron Energy BlueSolar PWM-Light Charge Controller 12/24V-10A with Timer & Load Disconnect
The Victron BlueSolar PWM-Light 12/24V-10A is a robust and compact PWM controller for small-scale 12V or 24V battery systems. It automatically detects system voltage, applies three-stage battery charging, and manages load output with manual or timed control. A low-voltage disconnect feature protects batteries from deep discharge. The controller includes electronic protections and is suited for basic lighting, rural solar, and battery maintenance applications.
Parameter Specification Model BlueSolar PWM-Light 12/24V-10A Battery Voltage 12V / 24V (auto-detect) Rated Charge Current 10 A Max PV Voltage 28 V (12V systems), 55 V (24V systems) Self-Consumption <10 mA Load Output Control Manual, low voltage disconnect, day/night timer Charge Stages Bulk, Absorption, Float Absorption Voltage 14.2 V / 28.4 V Float Voltage 13.8 V / 27.6 V Low Voltage Load Disconnect 11.2 V / 22.4 V Reconnect Threshold 13.1 V / 26.2 V (auto), 12.6 V / 25.2 V (manual) Protections Reverse polarity, overload, short circuit, over-temp Shutdown Behavior 130% load: 60s / 160% load: 5s / Short circuit: immediate Grounding Common positive Enclosure IP20 Terminal Size 5 mm² / AWG10 Dimensions (H x W x D) 70 x 133 x 33.5 mm Weight 0.2 kg Operating Temperature -20°C to +50°C Humidity (non-condensing) ≤ 95% Certifications IEC 62109-1, EN 61000-6-1/3, ISO 7637-2
Key Features:
- Three-stage charging for lead-acid batteries
- Timer-based lighting control with programmable night mode
- Low-voltage disconnect protects battery health
- Short circuit and overload protection
- Compact and efficient — ideal for lighting and signage
Applications:
- Solar-powered LED lighting
- Small-scale off-grid systems
- Battery maintenance for rural or mobile setups
Looking for a different Victron Blue Solar Charge Controllers? Explore our full Victron BlueSolar PWM product range.
Documents
Victron Energy BlueSolar PWM-Light 12_24V Size: 66,4 Kb -
