Victron Energy PMP482505110 - MultiPlus-II 48/5000/70-95 120V Inverter/Charger

SKU: CN VIPMP482505110

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron MultiPlus-II 48/5000/70-95 is a high-capacity inverter/charger engineered for 48V battery systems. With 5000 VA of continuous pure sine wave output, a 70 A intelligent charger, and a 95 A AC transfer switch, it is designed for demanding off-grid, mobile, and energy storage applications. It features PowerAssist, VE.Bus communication, dual AC outputs, and seamless integration with solar and backup systems.

Description
Ask a Question

Victron Energy MultiPlus-II 48/5000/70-95 120V VE.Bus Inverter/Charger is a top-tier solution for 48V systems, delivering power stability, intelligent charging, and flexible system integration. Its robust design and extensive feature set make it ideal for marine, mobile, off-grid, and ESS (Energy Storage System) applications.

Main Features:

5000 VA / 4000 W continuous pure sine wave AC output
70 A adaptive four-stage charger for Lithium, AGM, Gel, and Flooded batteries
95 A high-speed automatic AC transfer switch
Dual AC outputs: main UPS output and secondary output for non-critical loads
PowerAssist and PowerControl for managing generator or grid input
Supports parallel, split-phase, and three-phase operation (up to 6 units per phase)
VE.Bus communication for remote monitoring and configuration
Compatible with solar charge controllers and grid-tied inverters

Technical Specifications:

Function	Specification
Model	MultiPlus-II 48/5000/70-95
Continuous Output Power (25°C)	5000 VA / 4000 W
Continuous Output at 40°C / 65°C	3700 W / 3000 W
Peak Power	9000 W
AC Output Voltage / Frequency	120 V ±2%, 60 Hz ±0.1%
DC Input Voltage Range	38 – 66 V
Max Battery Charging Current	70 A
Charge Voltages	Absorption: 57.6 V, Float: 55.2 V, Storage: 52.8 V
Zero-load Power / AES / Search Mode	15 W / 10 W / 3 W
Transfer Switch	95 A
Auxiliary Output	48 A
VE.Bus Communication	Yes – for remote monitoring, split-phase/3-phase operation
Remote On/Off	Yes
Operating Temperature	-40 to +60 °C (fan-assisted)
Humidity (non-condensing)	Max 95%
Enclosure Material / Color	Steel, Blue (RAL 5012)
Ingress Protection	IP22
Dimensions (H x W x D)	676 x 330 x 164 mm (26.6 x 13.0 x 6.5 in)
Weight	32 kg (71 lbs)
Battery Connection	M8 bolts
AC Connection	35 mm² (2 AWG) screw terminal
Certifications	UL 1741, EN-IEC 60335-1/-2-29, CSA 22.2 107.1-16
EMC Standards	EN 55014-1/2, EN-IEC 61000-3-2/3, IEC 61000-6-1/2/3

Remote Monitoring & Accessories:

VE.Bus Smart Dongle – Enables Bluetooth and temperature/voltage sensing
VictronConnect App – Configuration and diagnostics via smartphone or PC
MK3-USB Interface – For setup using VE.Configure software
Cerbo GX / Ekrano GX – System monitoring, visualization, and internet connectivity
VRM Portal – Free cloud-based dashboard for remote monitoring and configuration

Applications: Ideal for large-scale 48V systems in off-grid homes, marine installations, commercial backup, or energy storage systems requiring robust inverter/charger performance with dual AC outputs.

Part Number: PMP482505110
Brand: Victron Energy
