Victron Energy PMP242305102 - MultiPlus-II 24/3000/70-50 120V (UL 485) Inverter/Charger

SKU: CN VIPMP242305102

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron MultiPlus-II 24/3000/70-50 (UL 458) is a powerful inverter/charger system combining 3000 VA of pure sine wave output, a 70 A adaptive battery charger, and a 50 A AC transfer switch. Built for 24V DC systems and compliant with UL 458 certification, it supports parallel, split-phase, and three-phase installations, PowerAssist technology, dual AC outputs, and full remote configuration via VictronConnect and VRM Portal. Ideal for mobile, off-grid, and backup applications.

Description
Ask a Question

Victron Energy MultiPlus-II 24/3000/70-50 120V VE.Bus Inverter/Charger (UL 458 Certified) is a robust and flexible energy solution for 24V DC systems. With high continuous power output, intelligent battery charging, and seamless integration with AC sources, it is perfect for demanding mobile, off-grid, and backup power setups.

Main Features:

3000 VA / 2400 W continuous true sine wave inverter
Adaptive 4-stage 70 A battery charger suitable for Lithium, AGM, Gel, and Flooded batteries
50 A high-speed AC transfer switch (<20 ms switching time)
Certified to UL 458 for mobile applications
PowerAssist and PowerControl to optimize generator or shore power use
Dual AC outputs: UPS output and secondary output active only when AC input is present
Supports parallel, split-phase, and three-phase operation (up to 6 units per phase)
Compatible with solar charge controllers and grid-tied inverters
VE.Bus port for remote monitoring and configuration

Technical Specifications:

Function	Specification
Model	MultiPlus-II 24/3000/70-50 (UL 458)
Continuous Output Power (25°C)	3000 VA / 2400 W
Output Power (40°C / 65°C)	2200 W / 1700 W
Peak Power	5500 W
AC Output Voltage / Frequency	120 V ±2% / 60 Hz ±0.1%
DC Input Voltage Range	19 – 33 V
Maximum Battery Charge Current	70 A
Battery Charge Voltages	Absorption: 28.8 V, Float: 27.6 V, Storage: 26.4 V
Zero-load Power / AES / Search Mode	13 W / 9 W / 3 W
Transfer Switch	50 A
Auxiliary Output	32 A
VE.Bus Communication	Yes – for remote access, parallel/split-phase/3-phase setups
Operating Temperature	-40 to +60 °C (fan assisted)
Humidity (non-condensing)	Max 95%
Enclosure Material / Color	Steel, Blue (RAL 5012)
Ingress Protection	IP22
Dimensions (H x W x D)	536 x 277 x 147 mm (21.1 x 10.9 x 5.8 in)
Weight	19 kg (42 lbs)
Battery Connection	M8 bolts
AC Connection	Screw terminals (6 AWG / 13 mm²)
Certifications	UL 458, EN-IEC 60335-1/-2-29, CSA 22.2 107.1-16
EMC Standards	EN 55014-1/-2, EN-IEC 61000-3-2/3, IEC 61000-6-1/2/3

Remote Monitoring & Accessories:

VE.Bus Smart Dongle – Adds Bluetooth monitoring and temperature sensing
VictronConnect App – Configure and monitor the unit via smartphone or PC
MK3-USB Interface – Enables advanced setup using VE.Configure software
Cerbo GX / Ekrano GX – Centralized system control and display
VRM Portal – Free cloud-based platform for remote monitoring and alerts

Applications: Ideal for mobile, marine, off-grid, and backup power systems using 24V battery banks and requiring UL 458 compliance, dual AC outputs, and advanced energy management capabilities.

Part Number: PMP242305102
Brand: Victron Energy
