The Victron MultiPlus 24/2000/50-50 (UL 458) is a robust and intelligent inverter/charger featuring a 2000 VA true sine wave inverter, a 50 A four-stage adaptive charger, and a 50 A AC transfer switch. UL 458 certified for mobile and commercial use, it supports PowerAssist, PowerControl, and parallel or three-phase configuration. Designed for 24V battery systems and compliant with stringent North American standards, it’s ideal for off-grid, RV, marine, and backup applications requiring high efficiency and flexible system integration.
- Description
- Ask a Question
-
Victron Energy MultiPlus 24/2000/50-50 120V VE.Bus Inverter/Charger (UL 458) is a powerful and reliable inverter/charger that integrates a true sine wave inverter, adaptive battery charger, and high-speed transfer switch in a compact enclosure. UL 458 certified, it is optimized for mobile and commercial-grade applications in North America.
Main Features:
- True sine wave inverter with 2000 VA / 1600 W continuous output
- 50 A adaptive 4-stage battery charger for Lithium, AGM, Gel, Flooded and Sealed batteries
- 50 A automatic transfer switch with <20 ms switching time
- UL 458 certified for safety and compliance in mobile applications
- PowerAssist and PowerControl to manage and enhance generator or shore power
- Parallel, three-phase, and split-phase operation (up to 6 units)
- Programmable relays and VE.Bus port for system integration and remote control
- Efficient standby modes: AES and Search Mode for low power draw
Technical Specifications:
Function Specification Model MultiPlus 24/2000/50-50 (UL 458) Continuous Output Power (25°C) 2000 VA / 1600 W Peak Power 4000 W AC Output Voltage / Frequency 120 V ±2% / 60 Hz ±0.1% DC Input Voltage Range 19 – 33 V Battery Charging Current (House Battery) 50 A Battery Charging Current (Starter Battery) 4 A Charge Voltages Absorption: 28.8 V, Float: 27.6 V, Storage: 26.4 V Efficiency (Max) 94% No-load Power Consumption 11 W No-load Power (Search Mode) 4 W Transfer Switch Rating 50 A Operating Temperature -40°C to +65°C, fan assisted cooling Enclosure Material / Color Aluminum / Blue RAL 5012 Ingress Protection IP21 Dimensions (H x W x D) 520 x 255 x 125 mm (20.5 x 10.0 x 5.0 in) Weight 13 kg (25 lbs) Battery Connection M8 bolts AC Connection Screw-terminal, 6 AWG (13 mm²) Standards & Certifications UL 458, EN-IEC 60335-1, EN-IEC 60335-2-29, UL 1741
Remote Monitoring & Accessories:
- VE.Bus Smart Dongle – Bluetooth connectivity and battery monitoring
- VictronConnect App – Configure and monitor using your smartphone or PC
- MK3-USB Interface – Advanced PC-based configuration and diagnostics
- Cerbo GX / Ekrano GX – Central system display and online monitoring
- VRM Portal – Free Victron cloud platform for remote access, alerts, and logging
Applications: Perfect for professional-grade mobile systems, RVs, off-grid homes, and marine power solutions where UL 458 compliance is required.
Part Number: PMP242200102
Brand: Victron EnergyDocuments
Victron Energy MultiPlus 2kVA-3kVA 120V Size: 872,2 Kb -
