Victron MultiPlus 120V 24/2000/50-50 (UL 458) Inverter/Charger - PMP242200102

SKU: CN VIPMP242200102

1-2 weeks delivery time

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron MultiPlus 24/2000/50-50 (UL 458) is a robust and intelligent inverter/charger featuring a 2000 VA true sine wave inverter, a 50 A four-stage adaptive charger, and a 50 A AC transfer switch. UL 458 certified for mobile and commercial use, it supports PowerAssist, PowerControl, and parallel or three-phase configuration. Designed for 24V battery systems and compliant with stringent North American standards, it’s ideal for off-grid, RV, marine, and backup applications requiring high efficiency and flexible system integration.

Description
Ask a Question

Victron Energy MultiPlus 24/2000/50-50 120V VE.Bus Inverter/Charger (UL 458) is a powerful and reliable inverter/charger that integrates a true sine wave inverter, adaptive battery charger, and high-speed transfer switch in a compact enclosure. UL 458 certified, it is optimized for mobile and commercial-grade applications in North America.

Main Features:

True sine wave inverter with 2000 VA / 1600 W continuous output
50 A adaptive 4-stage battery charger for Lithium, AGM, Gel, Flooded and Sealed batteries
50 A automatic transfer switch with <20 ms switching time
UL 458 certified for safety and compliance in mobile applications
PowerAssist and PowerControl to manage and enhance generator or shore power
Parallel, three-phase, and split-phase operation (up to 6 units)
Programmable relays and VE.Bus port for system integration and remote control
Efficient standby modes: AES and Search Mode for low power draw

Technical Specifications:

Function	Specification
Model	MultiPlus 24/2000/50-50 (UL 458)
Continuous Output Power (25°C)	2000 VA / 1600 W
Peak Power	4000 W
AC Output Voltage / Frequency	120 V ±2% / 60 Hz ±0.1%
DC Input Voltage Range	19 – 33 V
Battery Charging Current (House Battery)	50 A
Battery Charging Current (Starter Battery)	4 A
Charge Voltages	Absorption: 28.8 V, Float: 27.6 V, Storage: 26.4 V
Efficiency (Max)	94%
No-load Power Consumption	11 W
No-load Power (Search Mode)	4 W
Transfer Switch Rating	50 A
Operating Temperature	-40°C to +65°C, fan assisted cooling
Enclosure Material / Color	Aluminum / Blue RAL 5012
Ingress Protection	IP21
Dimensions (H x W x D)	520 x 255 x 125 mm (20.5 x 10.0 x 5.0 in)
Weight	13 kg (25 lbs)
Battery Connection	M8 bolts
AC Connection	Screw-terminal, 6 AWG (13 mm²)
Standards & Certifications	UL 458, EN-IEC 60335-1, EN-IEC 60335-2-29, UL 1741

Remote Monitoring & Accessories:

VE.Bus Smart Dongle – Bluetooth connectivity and battery monitoring
VictronConnect App – Configure and monitor using your smartphone or PC
MK3-USB Interface – Advanced PC-based configuration and diagnostics
Cerbo GX / Ekrano GX – Central system display and online monitoring
VRM Portal – Free Victron cloud platform for remote access, alerts, and logging

Applications: Perfect for professional-grade mobile systems, RVs, off-grid homes, and marine power solutions where UL 458 compliance is required.

Part Number: PMP242200102
Brand: Victron Energy
