Victron Energy PMP122120100 - MultiPlus 12/1200/50-16 120V VE.Bus Inverter/Charger

SKU: CN VIPMP122120100

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron MultiPlus 12/1200/50-16 combines a 1200 VA pure sine wave inverter, a 50 A adaptive battery charger, and a 16 A high-speed AC transfer switch in a single compact unit. Featuring PowerAssist and PowerControl technology, VE.Bus communication, and full remote monitoring capability, it's a versatile solution for mobile, marine, and off-grid systems.

Description
Ask a Question

Victron Energy MultiPlus 12/1200/50-16 VE.Bus Inverter/Charger (PMP122120100) is a high-performance, compact device that integrates an inverter, battery charger, and transfer switch in one enclosure. With true sine wave output, intelligent battery management, and smart power assistance features, it ensures reliable AC power and efficient charging in mobile, marine, or backup systems.

Main Features:

1200 VA / 1000 W continuous output and 2400 W peak power
Pure sine wave AC output – suitable for all sensitive electronics
50 A adaptive battery charger – with support for AGM, Gel, Flooded, and Lithium batteries
Integrated 16 A transfer switch – fast switching (<20 ms) between shore/generator and inverter
VE.Bus port – enables parallel, three-phase, and remote system integration
PowerAssist – boosts shore/generator power with battery power when needed
PowerControl – prevents overload of limited shore or generator supplies
Dual bank charging – includes 1 A trickle charge output for starter battery
Search Mode – reduces idle power consumption to 4 W
Programmable relay – can be used for alarms or generator start/stop
Remote On/Off/Charger-only switch via 3-pole terminal

Technical Specifications:

Model	MultiPlus 12/1200/50-16
SKU	PMP122120100
Battery Voltage	12 V
AC Output Voltage	120 VAC ±2%
Frequency	60 Hz ±0.1%
Continuous Output Power at 25°C	1200 VA / 1000 W
Continuous Output Power at 40°C	900 W
Continuous Output Power at 65°C	600 W
Peak Power	2400 W
Max Efficiency	93%
No-load Power Consumption	13 W
No-load Power in Search Mode	4 W
AC Input Voltage Range	95 – 140 V
Input Frequency Range	55 – 65 Hz
Charger Output Current	50 A (house battery) / 1 A (starter battery)
Absorption Charge Voltage	14.4 V
Float Charge Voltage	13.8 V
Storage Mode Voltage	13.2 V
Battery Temperature Sensor	Yes
VE.Bus Communication Port	1x RJ45
Remote On/Off	Yes (3-pole terminal)
Internal DC Fuse	200 A
Cooling	Fan assisted
Operating Temperature	-40°C to +65°C
Humidity (non-condensing)	Max 95%
Enclosure Material	Steel/ABS
Color	Blue RAL 5012
Protection Rating	IP21
Dimensions (H × W × D)	406 × 250 × 100 mm
Weight	8.2 kg
