Victron MultiPlus 120V 12/800/35-16 Inverter/Charger - PMP121800100

SKU: CN VIPMP121800100

1-2 weeks delivery time

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron MultiPlus 12/800/35-16 is a high-performance inverter/charger combining a true sine wave inverter with 800 VA output, a 35 A adaptive battery charger, and a fast 16 A AC transfer switch. Ideal for marine, mobile, and off-grid use, it supports PowerAssist, VE.Bus communication, and multiple battery chemistries. Its advanced functionality includes parallel and three-phase operation, low standby consumption, and full remote control via Victron’s monitoring solutions.

Description
Ask a Question

Victron Energy MultiPlus 12/800/35-16 120V VE.Bus Inverter/Charger is a powerful and intelligent inverter/charger that integrates multiple energy functions in one compact unit. Perfect for mobile, marine, and off-grid systems, it ensures efficient energy management with advanced features like PowerAssist and adaptive charging technology.

Main Features:

True sine wave inverter with 800 VA / 700 W continuous power output
35 A adaptive four-stage battery charger for Lithium, Sealed, AGM, Gel, and Flooded batteries
16 A high-speed transfer switch
PowerAssist and PowerControl to manage and supplement shore/generator power
VE.Bus communication port for remote monitoring and system integration
Search Mode to minimize power consumption during low load (only 2 W)
Programmable relay for custom alarms or generator control
Bluetooth configuration and monitoring via VictronConnect app with VE.Bus Smart Dongle
Parallel and three-phase operation (up to 6 units)

Technical Specifications:

Function	Specification
Model	MultiPlus 12/800/35-16
Continuous Output Power (25°C)	800 VA / 700 W
Peak Power	1600 W
AC Output Voltage / Frequency	120 V ±2% / 60 Hz ±0.1%
DC Input Voltage Range	9.5 – 17 V
Battery Charging Current (House)	35 A
Battery Charging Current (Starter)	1 A
Charge Voltage	Absorption: 14.4 V, Float: 13.8 V, Storage: 13.2 V
Zero-load Power / Search Mode	7 W / 2 W
Maximum Efficiency	92%
Transfer Switch Rating	16 A
Protection Features	Overload, Short Circuit, Battery Over/Undervoltage, Overtemperature, Ripple Input, 120 VAC feedback
Operating Temperature	-40°C to +65°C, fan-assisted cooling
Enclosure Material / Color	Steel/ABS / Blue (RAL 5012)
Ingress Protection	IP21
Dimensions (H x W x D)	360 x 240 x 100 mm (14.17 x 9.45 x 3.94 in)
Weight	6.4 kg (14.1 lb)
Communication Port	1 x VE.Bus (RJ45)

Remote Monitoring & Accessories:

VE.Bus Smart Dongle – Enables Bluetooth control and battery temperature monitoring
VictronConnect App – Free for iOS and Android devices
MK3-USB Interface – For advanced configuration using PC or tablet
Cerbo GX / Ekrano GX – Remote access and control via the Victron VRM Portal
VRM Portal – Free online monitoring and configuration with alerts and historical data

Applications: Ideal for mobile power systems, boats, off-grid homes, RVs, and backup power setups.

Part Number: PMP121800100
Brand: Victron Energy
