Victron Energy PIN482122500 - Phoenix 48/1200 VE.Direct NEMA 5-15R 120V Inverter

SKU: BB PIN482122500

1-2 weeks delivery time
Price incl. 19% VAT

ASK FOR QUOTE

Our managers will contact you and clarify the terms of the order

The Victron Phoenix 48/1200 VE.Direct inverter provides 1200 VA of continuous pure sine wave output at 120V from a 48V battery. With peak power up to 2200 W, NEMA 5-15R outlet, and VE.Direct interface for configuration and monitoring, it’s an ideal solution for mobile, marine, and off-grid power systems requiring reliable AC power.

Description
Ask a Question

Victron Energy Phoenix Inverter 48/1200 VE.Direct (PIN482122500) is a highly efficient and compact pure sine wave inverter that delivers 1200 VA continuous output and up to 2200 W surge power at 120V AC from a 48V DC battery. Equipped with a standard NEMA 5-15R outlet and VE.Direct communication port, it offers excellent configurability, low standby power consumption, and a robust enclosure designed for demanding environments.

Main Features:

1200 VA continuous output, 2200 W peak power – Handles high inrush loads like tools and appliances
Pure sine wave AC output – Safe for powering sensitive electronics
NEMA 5-15R outlet – Convenient standard AC connection
VE.Direct communication – Monitor and configure using VictronConnect app (via USB or Bluetooth dongle)
Configurable parameters include:
- Low voltage shutdown and restart thresholds
- AC output voltage (210–245V)
- Output frequency (50 or 60 Hz)
- ECO mode threshold and retry timing
Remote on/off functionality – Via two-pole terminal or external switch
Comprehensive electronic protections: overload, short circuit, over/under voltage, overheating, DC ripple

Technical Specifications:

Model	Phoenix Inverter 48/1200 VE.Direct
SKU	PIN482122500
Battery Voltage	48 V
Continuous Output Power (25°C)	1200 VA
Continuous Output Power (40°C)	1000 W
Peak Power	2200 W
Input Voltage Range	36.8 – 62.0 V
Low Voltage Shutdown	37.2 V (adjustable)
Restart Voltage	43.6 V (adjustable)
Max Efficiency	92%
No-load Power Consumption	10 W (ECO mode: 3.0 W)
Output Voltage / Frequency	120 VAC ±3%, 50/60 Hz ±0.1%
AC Output Socket	NEMA 5-15R
Remote On/Off	Yes (2-pole connector)
Communication Port	VE.Direct
Cooling	Fan-assisted
Enclosure Material	Steel and plastic (RAL 5012 blue)
Protection Rating	IP21
Operating Temperature Range	-40°C to +65°C (derating above 40°C)
Dimensions (H × W × D)	86 × 172 × 275 mm
Weight	5.5 kg
