The Victron Phoenix Inverter Smart 24/5000 (PIN242501000) delivers 5000VA (4000W) of continuous power and 10000W peak from a 24V battery, converting DC to stable 230V AC via a pure sine wave output. Designed for high-demand off-grid, marine, and industrial systems, it features a high-efficiency toroidal transformer, Bluetooth for wireless configuration, VE.Direct for remote integration, and an intelligent ECO mode to reduce idle consumption. Its programmable relay and extensive protections ensure reliable, safe operation under all conditions.
- Description
- Ask a Question
-
Victron PIN242501000 – Phoenix Inverter Smart 24/5000 230V
The Victron Phoenix Inverter Smart 24/5000 is a heavy-duty, high-capacity inverter delivering 4000W continuous (5000VA) AC power with a surge capacity of 10000W from a 24V battery source. Designed with Victron’s trusted toroidal transformer topology, it ensures stable voltage, reliable operation, and the ability to support high start-up loads. Built-in Bluetooth allows complete configuration and real-time monitoring via the VictronConnect app, while the VE.Direct port enables integration with Victron GX monitoring systems.
Key Features:
- Pure Sine Wave Output: Provides clean AC power compatible with all electronic devices and appliances.
- High Surge Capacity: 10000W peak power supports motors, compressors, and inductive loads.
- Bluetooth Connectivity: Wireless configuration and monitoring with the VictronConnect app.
- VE.Direct Communication Port: Enables USB and GX system integration for data logging and remote access.
- Dynamic Battery Cut-Off: Fully configurable to protect battery health under load.
- Programmable Relay: Customizable for general alarms, generator start/stop, or DC undervoltage control.
- ECO Mode: Reduces idle consumption by entering low-power standby during minimal loads.
- Remote On/Off: Supports ignition or external switching systems.
Technical Specifications:
Parameter Value Model Number PIN242501000 Input Voltage Range 18.6 – 34V DC Output Voltage 230V ±2% Output Frequency 50Hz or 60Hz ±0.1% Continuous Output Power at 25°C 5000VA / 4000W Output at 40°C / 65°C 3700W / 2800W Peak Power 10000W Max Efficiency 95% No-load Power Consumption 18W Power Consumption in ECO Mode 2.2W Programmable Relay Yes Bluetooth Built-in VE.Direct Port Yes Remote On/Off Yes Cooling Fan-assisted Operating Temperature -40°C to +65°C Humidity Max 95% (non-condensing) Protection Rating IP21 Enclosure Material Steel, RAL 5012 (blue) or RAL 9017 (black) Battery Connection 2 × M8 bolts AC Output Connection Screw terminals Dimensions (H × W × D) 595 × 295 × 160 mm Weight 29 kg
Certifications & Standards:
- Safety: EN 60335-1
- EMC: EN 55014-1 / EN 55014-2 / EN-IEC 61000-6-1, -6-2, -6-3
- Automotive: ECE R10-5 compliant
Compatible Accessories:
- VictronConnect app (iOS/Android)
- VE.Direct to USB Interface
- Victron GX Devices (e.g. Cerbo GX)
- BMV-712 Smart Battery Monitor
- Filax Automatic Transfer Switch
The Victron Phoenix Inverter Smart 24/5000 is engineered to provide maximum power output and smart functionality for advanced 24V systems. Whether used in off-grid homes, commercial mobile units, or yachts, it ensures stable, efficient AC power with wireless configurability and long-term reliability.
Documents
Victron Energy Inverter Smart 1600VA - 5000VA 12:24:48V Size: 841,5 Kb -
