The Victron Orion-Tr Smart 48/48-8A Isolated DC-DC Charger is a high-performance, Bluetooth-enabled power converter designed for 48V systems. It provides a continuous output current of 8A (380W at 40°C), supporting a wide input voltage range from 32 to 70 VDC and precise output voltage adjustment from 40 to 60 VDC. With IP43 protection, adaptive 3-stage charging algorithm, and full galvanic isolation, it's ideal for demanding automotive, marine, and industrial installations where stable, programmable power conversion is essential.
- Description
- Ask a Question
-
Victron Orion-Tr Smart 48V to 48V 8A Isolated DC-DC Charger
The Victron Orion-Tr Smart 48/48-8A is a fully isolated, programmable DC-DC charger engineered for advanced 48V applications. With its smart charging algorithm, Bluetooth connectivity, and compatibility with smart alternators (Euro 5/6), this unit ensures safe and efficient charging of service batteries from a 48V starter system. Whether used in off-grid vehicles, boats, or industrial setups, its durable design and precise control make it a reliable choice for mission-critical environments.
- Fully isolated input/output for enhanced system protection
- Smart 3-stage charging: Bulk, Absorption, Float (adaptive)
- Bluetooth connectivity for monitoring and programming via VictronConnect app
- Suitable for use as a battery charger or constant voltage power supply
- Remote on/off switch support
- IP43 ingress protection (electronics), IP22 (terminal area)
- Galvanic isolation: 200 VDC between input, output, and case
- Parallel operation possible to increase current output
Specification Value Model ORI484838120 Input Voltage Range 32 – 70 VDC Output Voltage (nominal) 48.2 VDC Output Voltage Range 40 – 60 VDC Continuous Output Current (at 40°C) 8 A Continuous Power Output (at 40°C) 380 W Peak Output Current (10 s) 15 A Short Circuit Current 25 A Efficiency 89% No Load Input Current < 80 mA Standby Current < 1 mA Protection IP43 (electronics), IP22 (connections) Operating Temperature -20 °C to +55 °C Dimensions (H × W × D) 130 × 186 × 70 mm Weight 1.6 kg DC Connection Type Screw terminals (max 16 mm²) Certifications EN 60950, ECE R10-5, EN 61000 Documents
Victron Energy Orion-Tr Smart DC-DC Charger Isolated Size: 353,6 Kb -
