SKU:
CN VIORI482438120
€ 292,84
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The Victron Orion-Tr Smart 48/24-16A (ORI482438120) is a high-efficiency, isolated DC-DC charger engineered for 48V to 24V battery charging. With a stable 24.2V output at up to 16A (380W), it features full galvanic isolation, Bluetooth programmability, and adaptive 3-stage charging. Compact and robust (130 × 186 × 70 mm, 1.6 kg), it is ideal for demanding marine, vehicle, and off-grid energy systems requiring secure, programmable power conversion.
- Description
- Ask a Question
-
Victron Orion-Tr Smart 48/24-16A Isolated DC-DC Charger – 380W
The Victron Orion-Tr Smart 48/24-16A (ORI482438120) is a fully programmable DC-DC charger designed for safe and efficient charging of 24V battery systems from a 48V input. Featuring galvanic isolation and a configurable 3-stage adaptive charging profile, it provides 16A of continuous current and up to 380W output power. With built-in Bluetooth for configuration and monitoring via the VictronConnect app, it's suitable for integration in industrial, marine, mobile, and off-grid setups.
Technical Specifications Model Orion-Tr Smart 48/24-16A (ORI482438120) Input Voltage Range 32 – 70 VDC Nominal Output Voltage 24.2 VDC Adjustable Output Voltage 18 – 30 VDC Continuous Output Current @ 40°C 16 A Peak Output Current (10 s) 25 A Short Circuit Output Current 40 A Continuous Output Power @ 25°C 430 W Continuous Output Power @ 40°C 380 W Efficiency 89% Galvanic Isolation 200 VDC (input/output/case) Bluetooth Configuration Yes (VictronConnect App) Charging Algorithm Adaptive 3-stage or fixed voltage Remote On/Off Yes (2-pole terminal) Standby Current < 1 mA No Load Input Current < 80 mA Protection Rating IP43 (electronics), IP22 (terminal area) Dimensions (H × W × D) 130 × 186 × 70 mm Weight 1.6 kg Connection Type Screw terminals (up to 16 mm² / AWG6) Certifications EN 60950, EN 61000, ECE R10-5
Key Features
- Galvanically isolated 48V to 24V DC-DC charger (16A, 380W)
- Bluetooth configuration and monitoring via VictronConnect
- Adaptive 3-stage battery charging or fixed voltage output
- Supports smart alternators and remote engine detection
- Parallel-capable for increased output current
Protection Features
- Over-voltage, short-circuit, and reverse polarity protection
- High-temperature current derating
- IP43-rated housing for harsh environments
Applications
- 48V to 24V conversion in telecom, marine, and vehicle systems
- Off-grid battery-to-battery charging
- Renewable energy system integration
- High-reliability power conversion in industrial DC setups
Documents
Victron Energy Orion-Tr Smart DC-DC Charger Isolated Size: 353,6 Kb -
