SKU:
CN VIORI481238120
€ 292,84
1-2 weeks delivery time
Price incl. 19% VAT
Price incl. 19% VAT
-
+
The Victron Orion-Tr Smart 48/12-30A (ORI481238120) is a high-current, isolated DC-DC charger engineered for 48V-to-12V conversion. It provides a stable 12.2V output at up to 30A continuous current (360W), featuring programmable Bluetooth control, smart alternator compatibility, and a robust 130 × 186 × 80 mm housing. With full galvanic isolation and adaptive 3-stage charging, it's ideal for marine, industrial, and off-grid systems with demanding energy needs.
- Description
- Ask a Question
-
Victron Orion-Tr Smart 48/12-30A Isolated DC-DC Charger – 360W
The Victron Orion-Tr Smart 48/12-30A (ORI481238120) is a fully programmable, isolated DC-DC charger designed for safely converting 48V power to 12V battery systems. With an output of 30A and 360W at 40°C, it supports adaptive 3-stage charging (Bulk, Absorption, Float), making it suitable for both lithium and lead-acid battery chemistries. Its integrated Bluetooth functionality allows full configuration and monitoring through the VictronConnect app.
Technical Specifications Model Orion-Tr Smart 48/12-30A (ORI481238120) Input Voltage Range 32 – 70 VDC Nominal Output Voltage 12.2 VDC Adjustable Output Voltage 10 – 15 VDC Continuous Output Current @ 40°C 30 A Peak Output Current (10 s) 40 A Short Circuit Output Current 60 A Continuous Output Power @ 25°C 430 W Continuous Output Power @ 40°C 360 W Efficiency 87% Galvanic Isolation 200 VDC between input/output/case Bluetooth Configuration Yes (VictronConnect App) Charging Algorithm Adaptive 3-stage or fixed voltage Remote On/Off Yes (2-pole terminal) Standby Current < 1 mA Protection Rating IP43 (electronics), IP22 (terminals) Dimensions (H × W × D) 130 × 186 × 80 mm Weight 1.8 kg Connection Type Screw terminals (max 16 mm² / AWG6) Certifications EN 60950, EN 61000, ECE R10-5
Key Features
- 30A DC-DC charger with 12.2V output from 48V input
- Bluetooth programmability via VictronConnect
- Smart 3-stage charging for lithium and lead-acid batteries
- Galvanically isolated for safe system integration
- Supports remote on/off and engine run detection
Protection Features
- Overvoltage, short circuit, and reverse polarity protection
- Thermal derating above 40°C
- Parallel-capable for higher output current
Applications
- 48V to 12V conversion for marine or mobile applications
- Charging auxiliary 12V batteries in 48V solar systems
- Off-grid and backup power scenarios
- Heavy-duty DC power infrastructure
Documents
Victron Energy Orion-Tr Smart DC-DC Charger Isolated Size: 353,6 Kb -
