SKU:
CN VIORI244840120
€ 292,84
1-2 weeks delivery time
-
+
The Victron Orion-Tr Smart 24/48-8.5A (ORI244840120) is a high-efficiency isolated DC-DC charger designed for converting 24V to 48V in demanding energy systems. Providing 8.5A continuous current at 48.2V and up to 400W power, it supports adaptive 3-stage charging, Bluetooth programmability, and smart alternator compatibility. Its compact IP43-rated housing (130 × 186 × 70 mm, 1.6 kg) makes it ideal for marine, industrial, and mobile battery systems.
- Description
- Ask a Question
-
Victron Orion-Tr Smart 24/48-8.5A Isolated DC-DC Charger – 400W
The Victron Orion-Tr Smart 24/48-8.5A (ORI244840120) is a fully programmable, isolated DC-DC charger designed for efficient and safe 48V battery charging from a 24V source. Featuring Bluetooth configuration and an adaptive 3-stage charging algorithm, it provides 8.5A output at up to 400W, ensuring optimal performance with lithium or lead-acid batteries. This model is ideal for advanced power systems in vehicles, boats, and off-grid setups requiring precise voltage conversion and isolation.
Technical Specifications Model Orion-Tr Smart 24/48-8.5A (ORI244840120) Input Voltage Range 16 – 35 VDC Nominal Output Voltage 48.2 VDC Adjustable Output Voltage 40 – 60 VDC Continuous Output Current @ 40°C 8.5 A Peak Output Current (10 s) 15 A Short Circuit Output Current 25 A Continuous Output Power @ 25°C 480 W Continuous Output Power @ 40°C 400 W Efficiency 89% Galvanic Isolation 200 VDC between input, output and case Bluetooth Configuration Yes (VictronConnect App) Charging Algorithm Adaptive 3-stage (Bulk, Absorption, Float) or fixed voltage Remote On/Off Yes (2-pole terminal) Standby Current < 1 mA Protection Rating IP43 (electronics), IP22 (connections) Dimensions (H × W × D) 130 × 186 × 70 mm Weight 1.6 kg Connection Type Screw terminals (max 16 mm² / AWG6) Certifications EN 60950, EN 61000, ECE R10-5
Key Features
- Isolated 24V to 48V DC-DC charger with 8.5A output
- Fully programmable via Bluetooth with VictronConnect
- Adaptive 3-stage or fixed-voltage charging mode
- Compatible with lithium and lead-acid batteries
- Smart alternator and remote on/off support
Protection Features
- Short-circuit, reverse polarity, and overvoltage protection
- Temperature-based current derating
- Galvanic isolation for system safety
Applications
- Charging 48V battery banks in vehicles and marine systems
- Converting 24V power to 48V for telecom or industrial loads
- Off-grid solar and hybrid energy systems
- DC distribution in commercial mobile applications
Documents
Victron Energy Orion-Tr Smart DC-DC Charger Isolated Size: 353,6 Kb -
