The Victron Orion-Tr Smart 24/24-12A (ORI242428120) is an isolated DC-DC charger delivering 280W at 24.2V and 12A. Fully programmable via Bluetooth and featuring an adaptive 3-stage charging algorithm, it provides stable power conversion in demanding mobile and industrial 24V systems. Housed in a compact 130 × 186 × 70 mm IP43-rated enclosure and weighing 1.3 kg, it supports smart alternators, remote on/off, and parallel operation.
- Description
- Ask a Question
-
Victron Orion-Tr Smart 24/24-12A Isolated DC-DC Charger – 280W
The Victron Orion-Tr Smart 24/24-12A (ORI242428120) is a professional-grade isolated DC-DC charger that provides reliable power conversion and battery charging in 24V systems. With 12A continuous output and 280W rated power, it’s ideal for powering sensitive equipment or charging service batteries. It supports Bluetooth configuration via the VictronConnect app, adaptive 3-stage charging, and remote control, while ensuring galvanic isolation between input and output.
Technical Specifications Model Orion-Tr Smart 24/24-12A (ORI242428120) Input Voltage Range 16 – 35 VDC Nominal Output Voltage 24.2 VDC Adjustable Output Voltage 18 – 30 VDC Continuous Output Current @ 40°C 12 A Peak Output Current (10 s) 15 A Short Circuit Output Current 30 A Continuous Output Power @ 25°C 320 W Continuous Output Power @ 40°C 280 W Efficiency 89% Galvanic Isolation 200 VDC (input/output/case) Bluetooth Configuration Yes (VictronConnect app) Charging Algorithm 3-stage (Bulk, Absorption, Float) or fixed voltage Remote On/Off Yes (2-pole terminal) Standby Current < 1 mA Protection Class IP43 (electronics), IP22 (terminal area) Dimensions (H × W × D) 130 × 186 × 70 mm Weight 1.3 kg Connection Type Screw terminals (max 16 mm² / AWG6) Certifications EN 60950, EN 61000, ECE R10-5
Key Features
- Isolated 24V to 24V DC-DC charger with 12A output
- Fully programmable via Bluetooth with VictronConnect
- Adaptive 3-stage charging algorithm or fixed output mode
- Remote on/off and engine detection for alternator support
- Supports parallel connection for increased output current
Protection Features
- Short-circuit and over-temperature protection
- Reverse polarity and overvoltage protection
- Galvanic isolation ensures system safety
Applications
- 24V vehicle and equipment charging systems
- Marine DC installations
- Off-grid and industrial automation setups
- Backup charging in dual-battery configurations
-
